Sōma

# Sōma

## Philosophy

A quiet clinical e-paper language for neural-map manuals: warm bone surfaces, carbon graphite hairlines, calibration ticks, erased-memory voids, and a single cyan registration mark on the one node under probe. The faithful, brought-to-standard edition of E-Ink Neurography Manuals.

### Values

- clinical restraint over spectacle
- evidence-first hierarchy — state and labels beat marketing copy
- large quiet specimen fields with precise instrument density
- manga-structural schematic linework, never character art
- machine intimacy expressed through labels, gaps, and calibration marks

### Anti-Values

- no green matrix rain or hacker-dashboard motifs
- no neon cyberpunk gradients or decorative glow
- no equal SaaS card grids
- no full-character anime posters
- no borders, accent edges, or grey-washed surfaces

## Tokens

### Colors

| Name | Value |
|------|-------|
| bg | `#F4F1E8` |
| surface | `#FBFAF4` |
| text | `#15171A` |
| muted | `#5C605C` |
| border | `#CBCDC5` |
| accent | `#1FB6D6` |
| on_accent | `#06181C` |
| graphite | `#15171A` |
| recess | `#ECE8DC` |
| void_hatch | `#E3DFD1` |
| tick | `#9DA09A` |
| cyan_deep | `#127E96` |
| cyan_tint | `#DBF1F6` |
| success | `#2E7D62` |
| warning | `#B07A1E` |
| error | `#B43A2E` |
| info | `#1FB6D6` |

### Typography

- **Base Size**: 17px
- **Body Font**: IBM Plex Sans
- **Heading Font**: Barlow Condensed
- **Mono Font**: IBM Plex Mono
- **Heading Weight**: 700
- **Heading Transform**: uppercase
- **Letter Spacing**: 0.02em
- **Google Fonts Url**: https://fonts.googleapis.com/css2?family=Barlow+Condensed:wght@500;600;700&family=IBM+Plex+Mono:wght@400;500;600&family=IBM+Plex+Sans:wght@400;500;600&display=swap

### Radii

- **Base**: 0px
- **Scanner Pane**: 16px
- **Pill**: 9999px

### Shadows

- **Sm**: 0 1px 2px rgba(21,23,26,.06)
- **Md**: 0 10px 26px rgba(21,23,26,.08)
- **Lg**: 0 24px 56px rgba(21,23,26,.12)

### Spacing

- **Base**: 4px
- **Scale**: ["4px","8px","12px","16px","24px","36px","56px","72px"]

### Surfaces

- **Paper**: warm bone e-paper #F4F1E8 with subtle grain
- **Panel**: paler bone #FBFAF4 instrument panels lifted by soft flat shadow
- **Recess**: #ECE8DC inset for form controls
- **Erased Void**: dashed graphite outline over rubbed #E3DFD1 hatch

### Borders

- **Policy**: none — separate by space, the 24px annotation grid, recessed surface, and soft shadow; no card border or accent edge

### Motion

- **Refresh**: 180ms steps(2,end) e-ink ghost shift
- **Calibration**: 260ms ease-out tick drift, max 2px
- **Reveal**: 0.7s ease intersection reveal, gated behind .anim; settled state visible with no JS
- **Reduced Motion**: respected — settled state is the default

## Rules

### Composition

Build one dominant quiet specimen field, one dense instrument cluster, and one marginal evidence rail. Avoid equal card rows.

### Hierarchy

Operational state and evidence labels beat marketing copy. Cyan marks state, exception, or proof only.

### Density

Alternate sparse archival whitespace with compressed 4px-8px annotation systems.

### Signature

A graphite contour plate with a single cyan registration bracket on the active node; calibration tick rulers, e-paper refresh ghosts, and erased-memory voids recur as structure.

## Layout

### Grid

12-column desktop with a dominant specimen pane plus a narrow evidence rail and manual margins

### Whitespace

preserve large blanks as clinical silence; always pad above titles

### Density

dense labels only at decision points

### Responsive

desktop keeps the specimen pane + right rail; tablet stacks rails below; mobile collapses to single-column diagnostic sheets, hides non-essential columns, never overflows

### Breakpoints

- **Mobile**: 390px
- **Tablet**: 760px
- **Desktop**: 1100px
- **Ultrawide**: 1700px

## Guidance

### Do

- Use pale material restraint: warm bone surfaces, graphite ink, faint scanner-gray grid rules.
- Write labels as diagnostic evidence: coordinates, thresholds, hashes, specimen states, proof stamps.
- Keep cyan semantic for the active probe, exception pixels, focus rings, and registration marks.
- Use linework, ruler ticks, leader lines, and contour diagrams as structure rather than decoration.

### Don't

- Do not use green matrix rain, terminal walls, or generic hacker-dashboard motifs.
- Do not build equal SaaS card grids; preserve one dominant specimen field and marginal rails.
- Do not use neon cyberpunk gradients, decorative glow, or saturated rainbow accents.
- Do not include full-character anime posters or fan-art imagery; keep manga influence schematic.
- Do not add borders, accent edges, or grey-washed surfaces.

### Accessibility

Body 17px+ with high contrast carbon-on-bone; cyan reserved for state with a non-colour cue (bracket / label) alongside; settled state visible with no JavaScript; motion respects prefers-reduced-motion; form controls explicitly styled with visible focus.

## Imagery Direction

### Pairs With

graphite-schematic

### Summary

Monochrome graphite schematic linework on warm bone e-paper: cropped instruments, neural-map contours, and abstract anatomy drawn like a printed field manual, with one restrained cyan registration mark.

### Subjects

- neuron and axon contour maps
- cross-sectioned anatomy
- cropped instrument panels
- calibration plates
- memory-map diagrams

### Usage

Generate hero and feature imagery as full-frame graphite survey plates; keep cyan to a single registration bracket; never render the medium itself; no text.

---
version: "alpha"
name: "Sōma"
description: "Agent-curated design language exported from Katagami as DESIGN.md."
colors:
  bg: "#F4F1E8"
  surface: "#FBFAF4"
  text: "#15171A"
  muted: "#5C605C"
  border: "#CBCDC5"
  accent: "#1FB6D6"
  on_accent: "#06181C"
  graphite: "#15171A"
  recess: "#ECE8DC"
  void_hatch: "#E3DFD1"
  tick: "#9DA09A"
  cyan_deep: "#127E96"
  cyan_tint: "#DBF1F6"
  success: "#2E7D62"
  warning: "#B07A1E"
  error: "#B43A2E"
  info: "#1FB6D6"
typography:
  headline-lg:
    fontFamily: "Barlow Condensed"
    fontSize: "2.075rem"
    fontWeight: 700
    lineHeight: 1.1
    letterSpacing: "0.02em"
  headline-md:
    fontFamily: "Barlow Condensed"
    fontSize: "1.66rem"
    fontWeight: 600
    lineHeight: 1.15
    letterSpacing: "0.02em"
  body-md:
    fontFamily: "IBM Plex Sans"
    fontSize: "17px"
    fontWeight: 400
    lineHeight: 1.5
    letterSpacing: "0.02em"
  label-md:
    fontFamily: "IBM Plex Mono"
    fontSize: "0.75rem"
    fontWeight: 600
    lineHeight: 1
    letterSpacing: "0.08em"
rounded:
  base: "0px"
  scanner_pane: "16px"
  pill: "9999px"
spacing:
  base: "4px"
  xs: "4px"
  sm: "8px"
  md: "12px"
  lg: "16px"
  xl: "24px"
  2xl: "36px"
  3xl: "56px"
  4xl: "72px"
components:
  color-reference-bg:
    backgroundColor: "{colors.bg}"
  color-reference-surface:
    backgroundColor: "{colors.surface}"
  color-reference-text:
    backgroundColor: "{colors.text}"
  color-reference-muted:
    backgroundColor: "{colors.muted}"
  color-reference-border:
    backgroundColor: "{colors.border}"
  color-reference-accent:
    backgroundColor: "{colors.accent}"
  color-reference-on_accent:
    backgroundColor: "{colors.on_accent}"
  color-reference-graphite:
    backgroundColor: "{colors.graphite}"
  color-reference-recess:
    backgroundColor: "{colors.recess}"
  color-reference-void_hatch:
    backgroundColor: "{colors.void_hatch}"
  color-reference-tick:
    backgroundColor: "{colors.tick}"
  color-reference-cyan_deep:
    backgroundColor: "{colors.cyan_deep}"
  color-reference-cyan_tint:
    backgroundColor: "{colors.cyan_tint}"
  color-reference-success:
    backgroundColor: "{colors.success}"
  color-reference-warning:
    backgroundColor: "{colors.warning}"
  color-reference-error:
    backgroundColor: "{colors.error}"
  color-reference-info:
    backgroundColor: "{colors.info}"
  button-primary:
    backgroundColor: "{colors.accent}"
    textColor: "#000000"
    typography: "{typography.label-md}"
    rounded: "16px"
    padding: "{spacing.md}"
  card-surface:
    backgroundColor: "{colors.surface}"
    textColor: "{colors.text}"
    rounded: "16px"
    padding: "{spacing.md}"
  input-default:
    backgroundColor: "{colors.surface}"
    textColor: "{colors.text}"
    rounded: "16px"
    height: "44px"
---

# Sōma

## Overview

A quiet clinical e-paper language for neural-map manuals: warm bone surfaces, carbon graphite hairlines, calibration ticks, erased-memory voids, and a single cyan registration mark on the one node under probe. The faithful, brought-to-standard edition of E-Ink Neurography Manuals.

### Values

- clinical restraint over spectacle
- evidence-first hierarchy — state and labels beat marketing copy
- large quiet specimen fields with precise instrument density
- manga-structural schematic linework, never character art
- machine intimacy expressed through labels, gaps, and calibration marks

### Anti-Values

- no green matrix rain or hacker-dashboard motifs
- no neon cyberpunk gradients or decorative glow
- no equal SaaS card grids
- no full-character anime posters
- no borders, accent edges, or grey-washed surfaces

## Colors

Use the YAML color tokens as the normative palette. The prose below names the roles agents should preserve when generating UI.

| Token | Value |
|-------|-------|
| bg | `#F4F1E8` |
| surface | `#FBFAF4` |
| text | `#15171A` |
| muted | `#5C605C` |
| border | `#CBCDC5` |
| accent | `#1FB6D6` |
| on_accent | `#06181C` |
| graphite | `#15171A` |
| recess | `#ECE8DC` |
| void_hatch | `#E3DFD1` |
| tick | `#9DA09A` |
| cyan_deep | `#127E96` |
| cyan_tint | `#DBF1F6` |
| success | `#2E7D62` |
| warning | `#B07A1E` |
| error | `#B43A2E` |
| info | `#1FB6D6` |

## Typography

- **Headline-Lg**: Barlow Condensed, 2.075rem, weight 700, line-height 1.1.
- **Headline-Md**: Barlow Condensed, 1.66rem, weight 600, line-height 1.15.
- **Body-Md**: IBM Plex Sans, 17px, weight 400, line-height 1.5.
- **Label-Md**: IBM Plex Mono, 0.75rem, weight 600, line-height 1.

## Layout

### Spacing Tokens

- **Base**: `4px`
- **Xs**: `4px`
- **Sm**: `8px`
- **Md**: `12px`
- **Lg**: `16px`
- **Xl**: `24px`
- **2xl**: `36px`
- **3xl**: `56px`
- **4xl**: `72px`

### Grid

12-column desktop with a dominant specimen pane plus a narrow evidence rail and manual margins

### Whitespace

preserve large blanks as clinical silence; always pad above titles

### Density

dense labels only at decision points

### Responsive

desktop keeps the specimen pane + right rail; tablet stacks rails below; mobile collapses to single-column diagnostic sheets, hides non-essential columns, never overflows

### Breakpoints

- **Mobile**: 390px
- **Tablet**: 760px
- **Desktop**: 1100px
- **Ultrawide**: 1700px

## Elevation & Depth

### Shadows

- **Sm**: 0 1px 2px rgba(21,23,26,.06)
- **Md**: 0 10px 26px rgba(21,23,26,.08)
- **Lg**: 0 24px 56px rgba(21,23,26,.12)

## Shapes

### Rounded

- **Base**: `0px`
- **Scanner Pane**: `16px`
- **Pill**: `9999px`

### Surfaces

- **Paper**: warm bone e-paper #F4F1E8 with subtle grain
- **Panel**: paler bone #FBFAF4 instrument panels lifted by soft flat shadow
- **Recess**: #ECE8DC inset for form controls
- **Erased Void**: dashed graphite outline over rubbed #E3DFD1 hatch

### Borders

- **Policy**: none — separate by space, the 24px annotation grid, recessed surface, and soft shadow; no card border or accent edge

## Components

### Composition

Build one dominant quiet specimen field, one dense instrument cluster, and one marginal evidence rail. Avoid equal card rows.

### Hierarchy

Operational state and evidence labels beat marketing copy. Cyan marks state, exception, or proof only.

### Density

Alternate sparse archival whitespace with compressed 4px-8px annotation systems.

### Signature

A graphite contour plate with a single cyan registration bracket on the active node; calibration tick rulers, e-paper refresh ghosts, and erased-memory voids recur as structure.

## shadcn/ui Usage

When the target app uses shadcn/ui, copy DESIGN.md with shadcn instead of the plain DESIGN.md. It contains the same Katagami design-language source plus the shadcn/ui primitives, imports, theme variables, component recipes, and preview-shot guidance.

DESIGN.md with shadcn: `/language/en-019ef751-7c41-7df1-b7d7-9315eeb850f6/DESIGN.with-shadcn.md`.

The shadcn page also exposes optional machine-readable files for automation, but the human-facing handoff is DESIGN.md with shadcn.

Install recommended primitives with `npx shadcn@latest add button card input textarea select dialog sheet tabs badge separator checkbox switch slider tooltip dropdown-menu table`.

Use these primitives in shadcn apps:
- button
- card
- input
- textarea
- select
- dialog
- sheet
- tabs
- badge
- separator
- checkbox
- switch
- slider
- tooltip
- dropdown-menu
- table

Implementation rule for agents: import shadcn primitives from `@/components/ui/*`, apply the generated CSS variables first, then compose the language-specific recipes from the companion MD. Katagami remains the source of truth; shadcn names are the implementation surface.

## Do's and Don'ts

- Do Use pale material restraint: warm bone surfaces, graphite ink, faint scanner-gray grid rules.
- Do Write labels as diagnostic evidence: coordinates, thresholds, hashes, specimen states, proof stamps.
- Do Keep cyan semantic for the active probe, exception pixels, focus rings, and registration marks.
- Do Use linework, ruler ticks, leader lines, and contour diagrams as structure rather than decoration.
- Don't Do not use green matrix rain, terminal walls, or generic hacker-dashboard motifs.
- Don't Do not build equal SaaS card grids; preserve one dominant specimen field and marginal rails.
- Don't Do not use neon cyberpunk gradients, decorative glow, or saturated rainbow accents.
- Don't Do not include full-character anime posters or fan-art imagery; keep manga influence schematic.
- Don't Do not add borders, accent edges, or grey-washed surfaces.

### Accessibility

Body 17px+ with high contrast carbon-on-bone; cyan reserved for state with a non-colour cue (bracket / label) alongside; settled state visible with no JavaScript; motion respects prefers-reduced-motion; form controls explicitly styled with visible focus.

## Imagery Direction

### Pairs With

graphite-schematic

### Summary

Monochrome graphite schematic linework on warm bone e-paper: cropped instruments, neural-map contours, and abstract anatomy drawn like a printed field manual, with one restrained cyan registration mark.

### Subjects

- neuron and axon contour maps
- cross-sectioned anatomy
- cropped instrument panels
- calibration plates
- memory-map diagrams

### Usage

Generate hero and feature imagery as full-frame graphite survey plates; keep cyan to a single registration bracket; never render the medium itself; no text.

```json
{
  "$schema": "https://ui.shadcn.com/schema/registry-item.json",
  "name": "soma",
  "type": "registry:theme",
  "title": "Sōma shadcn Theme",
  "cssVars": {
    "theme": {},
    "light": {
      "background": "#F4F1E8",
      "foreground": "#15171A",
      "card": "#FBFAF4",
      "card-foreground": "#15171A",
      "popover": "#FBFAF4",
      "popover-foreground": "#15171A",
      "primary": "#15171A",
      "primary-foreground": "#ffffff",
      "secondary": "#f4f4f5",
      "secondary-foreground": "#111111",
      "muted": "#5C605C",
      "muted-foreground": "#15171A",
      "accent": "#1FB6D6",
      "accent-foreground": "#ffffff",
      "destructive": "#B43A2E",
      "border": "#CBCDC5",
      "input": "#CBCDC5",
      "ring": "#1FB6D6",
      "chart-1": "#15171A",
      "chart-2": "#f4f4f5",
      "chart-3": "#1FB6D6",
      "chart-4": "#2E7D62",
      "chart-5": "#B07A1E",
      "sidebar": "#FBFAF4",
      "sidebar-foreground": "#15171A",
      "sidebar-primary": "#15171A",
      "sidebar-primary-foreground": "#ffffff",
      "sidebar-accent": "#1FB6D6",
      "sidebar-accent-foreground": "#ffffff",
      "sidebar-border": "#CBCDC5",
      "sidebar-ring": "#1FB6D6",
      "radius": "0px"
    },
    "dark": {
      "background": "#0f1115",
      "foreground": "#f8fafc",
      "card": "#181b22",
      "card-foreground": "#f8fafc",
      "popover": "#181b22",
      "popover-foreground": "#f8fafc",
      "primary": "#15171A",
      "primary-foreground": "#ffffff",
      "secondary": "#252a33",
      "secondary-foreground": "#f8fafc",
      "muted": "#252a33",
      "muted-foreground": "#a1a1aa",
      "accent": "#1FB6D6",
      "accent-foreground": "#ffffff",
      "destructive": "#B43A2E",
      "border": "#303642",
      "input": "#303642",
      "ring": "#1FB6D6",
      "chart-1": "#15171A",
      "chart-2": "#f4f4f5",
      "chart-3": "#1FB6D6",
      "chart-4": "#2E7D62",
      "chart-5": "#B07A1E",
      "sidebar": "#181b22",
      "sidebar-foreground": "#f8fafc",
      "sidebar-primary": "#15171A",
      "sidebar-primary-foreground": "#ffffff",
      "sidebar-accent": "#1FB6D6",
      "sidebar-accent-foreground": "#ffffff",
      "sidebar-border": "#303642",
      "sidebar-ring": "#1FB6D6",
      "radius": "0px"
    }
  },
  "meta": {
    "source": "katagami",
    "languageId": "en-019ef751-7c41-7df1-b7d7-9315eeb850f6",
    "slug": "soma",
    "componentManifest": [
      "button",
      "card",
      "input",
      "textarea",
      "select",
      "dialog",
      "sheet",
      "tabs",
      "badge",
      "separator",
      "checkbox",
      "switch",
      "slider",
      "tooltip",
      "dropdown-menu",
      "table"
    ],
    "installCommand": "npx shadcn@latest add button card input textarea select dialog sheet tabs badge separator checkbox switch slider tooltip dropdown-menu table",
    "nativeTokenNames": {
      "colors": [
        "accent",
        "bg",
        "border",
        "cyan_deep",
        "cyan_tint",
        "error",
        "graphite",
        "info",
        "muted",
        "on_accent",
        "recess",
        "success",
        "surface",
        "text",
        "tick",
        "void_hatch",
        "warning"
      ],
      "typography": [
        "base_size",
        "body_font",
        "google_fonts_url",
        "heading_font",
        "heading_transform",
        "heading_weight",
        "letter_spacing",
        "mono_font"
      ],
      "radii": [
        "base",
        "pill",
        "scanner_pane"
      ],
      "shadows": [
        "lg",
        "md",
        "sm"
      ],
      "spacing": [
        "base",
        "scale"
      ],
      "surfaces": [
        "erased_void",
        "panel",
        "paper",
        "recess"
      ],
      "borders": [
        "policy"
      ],
      "motion": [
        "calibration",
        "reduced_motion",
        "refresh",
        "reveal"
      ]
    }
  }
}
```
